ZBOX PRO edge CI342GL (ChromeOS Flex Certified)

The ChromeOS Flex compatible ZBOX PRO edge CI342GL enables a more robust option while maintaining a wide range of I/O connectivity in an ultra-thin and fanless design. ChromeOS Flex is the cloud-first, fast, easy-to-manage, and secure operating system for PCs, empowering ZBOX PRO edge CI342GL to become the ideal thin client, kiosk and digital signage solution at any workspace.

Feature Highlights:
- ChromeOS Flex certified (FREE Download)
- Intel Pentium processor N6415
- Dual DDR4-3200MHz SO-DIMM memory
- Dual Display Ready (HDMI 2.0, DisplayPort 1.2), 4K Ready
- M.2 2242/2280 key-M socket for SATA SSD or PCIe x2 NVME SSD
- 3x USB 3.1 (1 Type-C), RS-232 serial port
- Dual Gigabit LAN, Sparklan WiFi 5, Bluetooth 5
- Hardware Watchdog Timer

  • Overview
  • Specifications
  • Downloads


  • Brochure
  • User Manual
  • Files
    Related Products
    File Type
Product Specifications
Expand All
Computing System
  • Processor
    Intel Pentium N6415 (quad-core 1.2GHz up to 3.0GHz, 1.5MB cache)
  • Chipset
  • System Memory
    2x DDR4-3200MHz SO-DIMM slots (up to 32GB)
  • Graphics Engine
    Intel UHD Graphics (Integrated)
  • Video Output
    HDMI 2.0 (up to 4096x2160@60Hz)
    DisplayPort 1.2 (up to 4096x2160@60Hz)
    Up to Dual Display Support
  • Hard Drive
  • Storage
  • Optical Drive
  • mSATA
  • M.2
    1x M.2 2242/2280 key-M socket for SATA SSD / PCIe x2 NVME SSD
  • Card Reader
    3-in-1 (micro SD/SDHC/SDXC)
I/O Ports
  • Audio
    Mic / Stereo Audio
    8-channel Digital via HDMI
  • USB Port
    1x USB 3.1 Type-C
    2x USB 3.1
  • LAN
    Dual Gigabit Ethernet
  • Antenna
    Dual WiFI SMA connetor
  • Wifi
    Sparklan WiFi 5
  • Bluetooth
    Bluetooth 5
  • Legacy I/O
    RS-232 serial port
  • CIR Infrared Port
  • Thunderbolt
  • IDE
  • Kensington Lock
  • LED Indicators
  • Power Supply
    DC 19V/40W
  • Cooling system
    Passive cooling
  • ZBOX Dimensions
    147.2mm x 147.2mm x 31.1mm (5.8in x 5.8in x 1.22in)
  • Case Mounting
    VESA mount
  • Supported OS
    ChromeOS Flex ready (OS is not pre-loaded but FREE to download), Microsoft Windows 11 / Windows 10 / Windows 10 IoT ENT LTSC, Ubuntu 20.04.3 LTS Linux
  • Accessories
    1x VESA mounting kit (w/ 4 screws)
    2x Tri-band antenna
    1x Universal AC adapter
    Power Cord (bundled cable type dependent on region)
