ZBOX edge CI342GL (ChromeOS Flex Certified)

ZBOX-CI342GL

The ChromeOS Flex compatible ZBOX edge CI342GL enables a more robust option while maintaining a wide range of I/O connectivity in an ultra-thin and fanless design. ChromeOS Flex is the cloud-first, fast, easy-to-manage, and secure operating system for PCs, empowering ZBOX edge CI342GL to become the ideal thin client, kiosk and digital signage solution at any workspace.

Feature Highlights:
- ChromeOS Flex certified (FREE OS Download)
- Ultra-thin at just 1.26" / 32.1mm in height
- Passively cooled for silent performance
- Intel Pentium processor N6415
- DDR4 memory slot (up to 32GB)
- M.2 PCIe 3.0 x2 / SATA SSD support
- 3 x USB 3.1 (1 Type-C)
- Sparklan WiFi 5, Dual Gigabit LAN, Bluetooth 5
- 4K @60Hz ready with HDMI 2.0b and DisplayPort 1.2
- VESA Mount Ready

Overview
Specifications
Downloads

Download

Brochure

Files

Related Products
File Type
OS

Product Specifications

Expand All

Computing System

Processor

Intel Pentium Processor N6415 (quad-core 1.2GHz, up to 3.0GHz)
Chipset

Intel
System Memory

2 x DDR4-3200/2666 SODIMM slot (up to 32GB)

Graphics

Graphics Engine

Intel UHD Graphics (Integrated)
Video Output

HDMI 2.0b (up to 4096x2160@60Hz)
DisplayPort 1.2 (up to 4096x2160@60Hz)
Up to Dual Display Support

Storage

Hard Drive

N/A
Mass Storage

N/A
Optical Drive

N/A
mSATA

N/A
M.2

M.2 2242/2280 PCIe 3.0 x2 / SATA SSD slot
Card Reader

Micro SDHC/SDXC

I/O Ports

Audio

Stereo output / Microphone, 8 channel via HDMI
USB Port

1 x USB 3.1 (Front)
1 x USB 3.1 Type-C (Front)
1 x USB 3.1 (Rear)
LAN

2 x 10/100/1000 Mbps
Antenna

Yes
Wifi

Sparklan WiFi 5
Bluetooth

Bluetooth 5
Legacy I/O

N/A
CIR Infrared Port

N/A
Thunderbolt

N/A
USB
IDE

N/A
VGA

N/A

Mechanical

Kensington Lock

Yes
LED Indicators

Power
Power Supply

AC Adapter
O/P: DC 19V/40W
Cooling system

Passive
ZBOX Dimensions

147.2mm x 147.2mm x 32.1mm (5.80in x 5.80in x 1.26in)
Case Mounting

VESA Mount ready

Miscellaneous

Supported OS

ChromeOS Flex ready (OS is not pre-loaded but FREE to download from Chrome Enterprise), Windows 11 / 10 (64-bit) ready
Accessories

Wi-Fi Antenna
2 x VESA Mount Bracket (with 4 screws)
AC Adapter
Power Cord (bundled cable type dependent on region)
Warranty Card
Quick Install Guide

Available SKU

Available SKU

ZBOX-CI342GL-BE
ZBOX-CI342GL-BE1
ZBOX-CI342GL-J
ZBOX-CI342GL-U
ZBOX-CI342GL-K
ZBOX-CI342GL-AUS
