Mini PCs / ZBOX M Series
ZBOX MI553 (Barebone)
ZBOX-MI553

A sleek design maximizing breathability and integration with future fast technologies make the new modern ZOTAC ZBOX. MI553 brings speeding performance to the forefront featuring a 7th Gen Intel Core processor based on the Kaby Lake architecture, a revolutionary Optane Memory technology, Thunderbolt 3 and next-gen USB 3.1. Enjoy a faster experience in work or home entertainment with this multi-functional do it all Mini PC.

7th Gen Intel Kaby Lake Core Processor
Optane Memory ready
Thunderbolt 3
Native 4K support
USB 3.1 Gen2 Ports
Whisper Quiet

  • Overview
  • Specifications
  • Awards/Reviews
  • News/Blog
  • Downloads
News/Blog
Download
  • Brochure
  • Files
    Related Products
    File Type
    OS
Product Specifications
Expand All
Computing System
  • Processor
    Intel Core i5-7300HQ Processor (quad-core 2.5GHz, up to 3.5GHz)
  • Chipset
    Intel
  • System Memory
    2 x DDR4-2400/2133 SODIMM Slot (up to 32GB)
Graphics
  • Graphics Engine
    Intel HD Graphics 630 (Integrated)
  • Video Output
    DisplayPort 1.2 (4096x2160 @ 60Hz)
    HDMI 2.0 (3840x2160 @ 60Hz)
Storage
  • Hard Drive
    1 x 2.5" SATA 6Gbps HDD/SSD Slot
  • Mass Storage
  • Optical Drive
  • mSATA
  • M.2
    1 x M.2 SSD SATAIII slot (22/42), 1 x M.2 NVMe PCIe x4 SSD / Intel Optane memory slot (22/42,22/60,22/80)
  • Card Reader
    3-in-1 (SD/SDHC/SDXC) / USB 3.1 port Combo
I/O Ports
  • Audio
    Stereo output , Microphone
  • USB Port
    1 x USB 3.1 Type-C (front)
    4 x USB 3.0 (back)
  • LAN
    10/100/1000 Mbps
  • Antenna
    Yes
  • Wifi
    802.11ac
  • Bluetooth
    Bluetooth 4.2
  • Legacy I/O
  • CIR Infrared Port
  • Thunderbolt
    1 x Thunderbolt 3
  • USB
  • IDE
  • VGA
Mechanical
  • Kensington Lock
  • LED Indicators
    Power
  • Power Supply
    AC Adapter
    O/P: DC 19.5V/120W
  • Cooling system
    Fan + Heatsink
  • ZBOX Dimensions
    184.6mm x 184.6mm x 71.5mm (7.27in x 7.27in x 2.81in)
  • Case Mounting
    VESA mount
Miscellaneous
  • Supported OS
    Windows 10 64-bit
  • Accessories
    1 x Wi-Fi antenna
    1 x VESA mount (with 4 screws)
    1 x AC Adapter
    1 x Power Cord (bundled cable type dependent on region)
    1 x Warranty Card
    1 x User Manual
    1 x Quick Install Guide
    1 x USB drive with O/S driver
    1 x Driver Disc
Available SKU
  • Available SKU
    ZBOX-MI553-BE
    ZBOX-MI553-U
    ZBOX-MI553-J
    ZBOX-MI553-K
    ZBOX-MI553-AUS
