MAGNUS EN1060K (Barebone)
ZBOX-EN1060K

MAGNUS EN1060K transforms the entertainment experience with hardware that captures the essence of gaming. Designed to push the limit of your gaming experience and to strike the perfect balance between power and thermal for whisper quiet performance. Superior gaming performance with native 4K display output are the least you can expect from this spectacular Mini PC.

FEATURES:
- Powerful Intel 7th Gen Kaby Lake processor enables big number crunching
- GeForce GTX 1060 graphics enables playing AAA titles in ultra-fine quality
- Up to 32GB DDR4-2400 memory support for the super multitasker
- Supports up to 4 displays
- Supports USB 3.1 Type-C connection

  • Overview
  • Specifications
  • Awards/Reviews
  • Downloads

Download
  • Brochure
  • Files
    Related Products
    File Type
    OS
Product Specifications
Expand All
Computing System
  • Processor
    Intel Core i5-7500T (quad-core, 2.7 GHz, up to 3.3 GHz)
  • Chipset
    Intel 100 Series, NVIDIA
  • System Memory
    2 x DDR4-2400/2133 SODIMM Slots (up to 32GB)
Graphics
  • Graphics Engine
    GeForce® GTX 1060 6GB GDDR5 192-bit
  • Video Output
    2 x HDMI 2.0
    2 x DisplayPort 1.3
Storage
  • Hard Drive
    1 x 2.5-inch SATA 6.0 Gbps HDD/SSD bay
  • Mass Storage
    N/A
  • Optical Drive
    N/A
  • mSATA
    None
  • M.2
    1 x M.2 PCIEx4 / SATA SSD slot (22/42,22/60,22/80)
  • Card Reader
    3-in-1 (SD/SDHC/SDXC)
I/O Ports
  • Audio
    Microphone, Headphone
  • USB Port
    2 x USB 3.0
    1 x USB 3.1 Type-C
    1 x USB 3.1
    2x USB 2.0
  • LAN
    Dual Gigabit LAN
  • Antenna
    1 x WiFI SMA connetor
  • Wifi
    802.11ac/b/g/n
  • Bluetooth
    Bluetooth 4.2
  • Legacy I/O
    None
  • CIR Infrared Port
    Yes
  • Thunderbolt
    None
  • USB
  • IDE
  • VGA
Mechanical
  • Kensington Lock
    Yes
  • LED Indicators
    Power, HDD, WiFi
  • Power Supply
    AC Adapter
    O/P: DC 19.5V/180W
  • Cooling system
    Fan + Heatsink
  • ZBOX Dimensions
    210mm x 203mm x 62.2mm
  • Case Mounting
    None
Miscellaneous
  • Supported OS
    Windows 8.1/10 (32/64-bit)
  • Accessories
    WiFi antenna
    AC Adapter
    Power Cord
    Warranty Card
    User Manual
    Quick Install Guide
    USB drive with O/S driver
    Driver Disc
Available SKU
  • Available SKU
    ZBOX-EN1060K
    ZBOX-EN1060K-BE
    ZBOX-EN1060K-U
    ZBOX-EN1060K-J
    ZBOX-EN1060K-AUS
