MI545 Nano Plus
ZBOX-MI545NANO-P

Redefining workstation performance and reliability in the most compact of solutions - the ZBOX nano. Incorporating Intel AMT technology to deliver efficiency, effectiveness, protection and productivity for both back and front end usability. With Intel Skylake CPU's processing power combined with blazing connectivity potential, a green powerhouse that provides stellar workstation performance experience awaits.

  • Overview
  • Specifications
  • Downloads
Download
  • Brochure
  • User Manual
  • Files
    Related Products
    File Type
    OS
Product Specifications
Expand All
Computing System
  • Processor
    Intel Core i5-6300U, dual core 2.4 GHz, up to 3.0 GHz
  • Chipset
    Intel SoC
  • System Memory
    4GB DDR3L-1600 (up to 16GB)
Graphics
  • Graphics Engine
    Intel HD Graphics 520
  • Video Output
    DisplayPort: 3840x2160 @ 60Hz
    HDMI: 4096x2160 @ 24Hz
Storage
  • Hard Drive
    120GB 2.5" SATA SSD
  • Mass Storage
    N/A
  • Optical Drive
    N/A
  • mSATA
    N/A
  • M.2
    N/A
  • Card Reader
    3-in-1 (SD/SDHC/SDXC)
I/O Ports
  • Audio
    Stereo output, Microphone
  • USB Port
    2 x USB 3.1 Type-C (front)
    3 x USB 3.0 (1 front, 2 rear)
    2 x USB 2.0 (rear)
  • LAN
    2 x 10/100/1000 Mbps
  • Antenna
    Yes
  • Wifi
    802.11ac
  • Bluetooth
    Bluetooth 4.1
  • Legacy I/O
    N/A
  • CIR Infrared Port
    N/A
  • Thunderbolt
    N/A
  • USB
  • IDE
  • VGA
Mechanical
  • Kensington Lock
    N/A
  • LED Indicators
    Power, HDD
  • Power Supply
    AC Adapter
    O/P: DC 19V/65W
  • Cooling system
    Fan + Heatsink
  • ZBOX Dimensions
    127.8mm x 126.4mm x 50.8mm
  • Case Mounting
    VESA mount kit
Miscellaneous
  • Supported OS
    Windows 10, 8.1 (32/64-bit)
  • Accessories
    1 x WiFi antenna
    1 x VESA mount
    1 x AC Adapter
    1 x Power Cord
    1 x Warranty Card
    1 x User Manual
    1 x Quick Start Guide
    1 x USB drive with O/S driver
    1 x Driver Disc
Available SKU
  • Available SKU
    ZBOX-MI545NANO-BE
    ZBOX-MI545NANO-U
    ZBOX-MI545NANO-J
