MAGNUS EN1060 with Windows 10
ZBOX-EN1060-W2B/W3B/W4B

MAGNUS EN1060 transforms the entertainment experience with hardware that captures the essence of gaming. Designed to push the limit of your gaming experience and to strike the perfect balance between power and thermal for whisper quiet performance.

The power of Intel Skylake Core i5-6400T processor and graphical prowess of NVIDIA GeForce® GTX 1060 come together to create a superior VR and gaming performance, enabling native 4K display output and supporting up to 4 displays. MAGNUS EN1060 supports dual storage solutions to provide flexibility, and connects with 802.11ac Wi-Fi and dual gigabit LAN for high speed experience.

  • Overview
  • Specifications
  • Downloads
Download
  • Brochure
  • User Manual
  • Files
    Related Products
    File Type
    OS
Product Specifications
Expand All
Computing System
  • Processor
    Intel Core i5-6400T (quad-core, 2.2 GHz, up to 2.8 GHz)
  • Chipset
    Intel 100 Series, NVIDIA
  • System Memory
    8GB (up to 32GB)
Graphics
  • Graphics Engine
    GeForce® GTX 1060 6GB GDDR5 192-bit
  • Video Output
    2 x HDMI 2.0
    2 x DisplayPort 1.3
Storage
  • Hard Drive
    1TB 2.5" HDD
  • Mass Storage
    N/A
  • Optical Drive
    N/A
  • mSATA
    None
  • M.2
    120GB M.2 SATA SSD
  • Card Reader
    3-in-1 (SD/SDHC/SDXC)
I/O Ports
  • Audio
    Microphone, Headphone
  • USB Port
    2 x USB 3.0
    1 x USB 3.1 Type-C
    1 x USB 3.1
    2x USB 2.0
  • LAN
    Dual Gigabit LAN
  • Antenna
    1 x WiFI SMA connetor
  • Wifi
    802.11ac/b/g/n
  • Bluetooth
    Bluetooth 4.0
  • Legacy I/O
    None
  • CIR Infrared Port
    Yes
  • Expansion
    None
  • USB
  • IDE
  • VGA
Mechanical
  • Kensington Lock
    Yes
  • LED Indicators
    Power, HDD, WiFi
  • Power Supply
    AC Adapter
    O/P: DC 19.5V/180W
  • Cooling system
    Fan + Heatsink
  • ZBOX Dimensions
    210mm x 203mm x 62.2mm
  • Case Mounting
    None
Miscellaneous
  • Supported OS
    Windows 10 Home Pre-installed
  • Accessories
    WiFi antenna
    AC Adapter
    Power Cord
    Warranty Card
    User Manual
    Quick Install Guide
    USB drive with O/S driver
    Driver Disc
    O/S Recovery DVD
Available SKU
  • Available SKU
    ZBOX-EN1060-W2B
    ZBOX-EN1060-W3B
    ZBOX-EN1060-W4B
    ZBOX-EN1060-U-W2B
    ZBOX-EN1060-BE-W2B
    ZBOX-EN1060-BE-W3B
