MAGNUS EK71060 PLUS
ZBOX-EK71060-P

MAGNUS EK71060 transforms the entertainment experience with hardware that captures the essence of gaming. Designed to push the limit of your gaming experience and to strike the perfect balance between power and thermal for whisper quiet performance. Native 4K display output and superior Full HD gaming performance are the least you can expect from this spectacular Mini PC.

FEATURES:
- Intel 7th Gen Kaby Lake processor
- ZOTAC GeForce GTX 1060 desktop graphics card
- Up to 32GB DDR4-2400 memory support
- Supports up to 4 displays
- 2x USB 3.1 Gen 2 ports (1 Type-C)
- Intel Optane Memory ready
- NVMe PCIe x4 M.2 SSD ready
- VR Ready

  • Overview
  • Specifications
  • Downloads
Download
  • Brochure
  • User Manual
  • Files
    Related Products
    File Type
    OS
Product Specifications
Expand All
Computing System
  • Processor
    Intel Core i7-7700HQ (quad-core 2.8 GHz, up to 3.8 GHz)
  • Chipset
    Intel, NVIDIA
  • System Memory
    8GB DDR4 (up to 32GB)
Graphics
  • Graphics Engine
    ZOTAC GeForce® GTX 1060 3GB GDDR5 192-bit
  • Video Output
    HDMI 2.0b
    3 x DisplayPort 1.4
    DL-DVI-D
Storage
  • Hard Drive
    1TB 2.5-inch SATA HDD
  • Mass Storage
    Intel Optane memory slot (2242, 2260, 2280)
  • Optical Drive
  • mSATA
  • M.2
    120GB M.2 SATA SSD
  • Card Reader
    3-in-1 (SD/SDHC/SDXC)
I/O Ports
  • Audio
    Microphone, Headphone
  • USB Port
    1 x USB 3.1 Type-C
    1 x USB 3.1
    4 x USB 3.0
  • LAN
    Dual Gigabit LAN
  • Antenna
    1 x WiFI SMA connetor
  • Wifi
    802.11ac/b/g/n
  • Bluetooth
    Bluetooth 4.2
  • Legacy I/O
  • CIR Infrared Port
  • Thunderbolt
  • USB
  • IDE
  • VGA
Mechanical
  • Kensington Lock
    Yes
  • LED Indicators
    Power, HDD, WiFi
  • Power Supply
    AC Adapter
    O/P: DC 19.5V/230W
  • Cooling system
    Fan + Heatsink
  • ZBOX Dimensions
    225mm x 203mm x 128mm (8.86in x 7.99in x 5.04in)
  • Case Mounting
    None
Miscellaneous
  • Supported OS
    Windows 10/8.1 (32/64-bit)
  • Accessories
    WiFi antenna
    AC Adapter
    Power Cord (bundled cable type dependent on region)
    Warranty Card
    User Manual
    Quick Install Guide
    USB drive with O/S driver
    Driver Disc
Available SKU
  • Available SKU
    ZBOX-EK71060-P-BE
    ZBOX-EK71060-P-U
    ZBOX-EK71060-P-J
    ZBOX-EK71060-P-K
