ZBOX edge MI626 (Barebone)
ZBOX-MI626

Ultra-thin design meets next-gen performance in the new ZBOX M Series edge. Powered by the latest 11th Generation Intel® Core™ processor and support for high-speed 3200 MHz DDR4 memory, the ZBOX edge MI626 features full desktop PC functionality and flexibility in a low-profile chassis, making it a powerful and nimble solution for edge computing, remote manageability, and everyday productivity in space-limited environments. Streamline data processing with dual SSD storage support and a wide array of I/O connectivity including Thunderbolt 4, USB 3.1, dual Gigabit Ethernet, WiFi 5 and Bluetooth 5. With the HDMI and DisplayPort 1.4 outputs, create and view more in a dual monitor setup that supports incredible 4K at 60Hz resolution.

- 11th Gen Intel Core i3 Processor
- Intel UHD graphics
- Up to 64GB DDR4 SO-DIMM memory support
- Dual M.2 SSD slots
- Windows 11 Ready
- 4K@60Hz display support via HDMI 2.0 and DisplayPort 1.4
- High-speed data transfers with Thunderbolt 4 and USB 3.1 ports
- Dual Gigabit Ethernet, Wi-Fi 5 and Bluetooth 5
- VESA Mount Ready
- Ultra slim at just 1.12 in / 28.5mm in height

  • 概要
  • 仕様
  • ダウンロード
ダウンロード
  • パンフレット
  • ユーザーマニュアル
  • ファイル選択
    Related Products
    ファイル種類
    OS
製品仕様
すべてを展開
PCシステム
  • プロセッサ
    Intel Core i3-1115G4 (dual-core 3.0GHz, up to 4.1GHz)
  • チップセット
    Intel
  • システムメモリ
    2 x DDR4-3200/2666 SODIMM slot (up to 64GB)
グラフィックス
  • グラフィックスエンジン
    Intel UHD Graphics (Integrated)
  • 出力端子
    HDMI 2.0 (up to 3840x2160@60Hz)
    DisplayPort 1.4 (up to 4096x2160@60Hz)
ストレージ
  • ハードドライブ
    N/A
  • ストレージ
    N/A
  • オプティカルドライブ
    N/A
  • mSATA
    N/A
  • M.2
    1 x M.2 NVMe SSD (22/42), 1 x M.2 NVMe/SATA SSD (22/80)
  • カードリーダー
    Micro SDHC/SDXC
I/O ポート
  • オーディオ
    Stereo output / Microphone, 8ch via HDMI
  • USB ポート
    1 x USB 3.1 (Front)
    2 x USB 3.1 (Rear)
  • LAN
    2 x 10/100/1000 Mbps
  • アンテナ
    Yes
  • Wifi
    WiFi 5
  • Bluetootj
    Bluetooth 5
  • レガシー I/O
    N/A
  • CIR赤外線ポート
    N/A
  • Thunderbolt
    1 x Thunderbolt 4
  • IDE
    N/A
その他仕様
  • ケンジントンロック
    Yes
  • LEDインジケーター
    Power
  • 電源サプライ
    AC Adapter
    O/P: DC 19V/65W
  • 冷却システム
    Fan + Heatsink
  • ZBOX寸法
    149.5mm x 149.5mm x 28.5mm (5.89in x 5.89in x 1.12in)
  • ケースマウンタ
    VESA Mount ready
付属品
  • 対応OS
    Windows 10 64-bit / 11 ready
  • アクセサリー
    Wi-Fi antenna
    2 x VESA mount bracket (with 4 screws)
    AC Adapter
    Power Cord (bundled cable type dependent on region)
    Warranty Card
    Quick Install Guide
    USB drive with O/S driver
Available SKU
  • Available SKU
    ZBOX-MI626-BE
    ZBOX-MI626-J
    ZBOX-MI626-U
    ZBOX-MI626-K
    ZBOX-MI626-AUS
    ZBOX-MI626-BE1
