ZBOX PRO CI329 nano (Barebone)
ZP-CI329NANO
Uniqueness defines this high performance and versatile platform. With an Intel Celeron N4100 processor at its core, the ZBOX PRO CI329 nano puts the incredible power of Intel UHD Graphics in your projects, boosting efficiency for those resource intensive applications. It powers everything from research labs to Ultra HD Digital Signage showcases. The fanless design enables this unit to be installed even at the most sound sensitive location and there is an array of connectivity options including HDMI, DisplayPort, VGA, RS-232 serial port, USB 3.0 ports, and Dual Gigabit Ethernet.


- Intel Celeron N4100 quad-core processor
- Dual DDR4-2400MHz SO-DIMM memory
- Max 3 displays (HDMI 2.0, DisplayPort 1.2, VGA)
- 1x SATA-III 2.5" HDD/SSD bay
- 1x M.2 2242/2260 key-M socket for SATA SSD
- 4x USB 3.0 (1x Type-C), 1x RS-232 serial port
- 2x Gigabit Ethernet LAN, support Wake-on-LAN
- IEEE 802.11ac/a/b/g/n WIFI
- Support Windows 10 and Ubuntu Linux
- Hardware watchdog timer (Timeout value = 1 ~ 255, Unit = minute/second)

  • 產品簡介
  • 產品規格
  • 動態/博客
  • 下載
動態/博客
下載
  • 小冊子
  • 用戶手册
  • 檔案
    Related Products
    檔案類別
    作業系統
產品規格
詳盡顯示
電腦系統
  • 處理器
    Intel Celeron N4100 (quad-core 1.1GHz up to 2.4GHz, 4MB cache)
  • 晶片組
    Intel
  • 系統記憶
    2x DDR4-2400MHz dual-channel SO-DIMM slots, up to 8GB
圖像處理
  • 圖像處理器
    Intel UHD Graphics 600 (Integrated)
  • 輸出
    1x HDMI 2.0, max resolution 4096x2160@60Hz
    1x DisplayPort 1.2, max resolution 4096x2160@60Hz
    1x VGA, max resolution 1920x1200@60Hz
內存
  • 硬碟
  • 儲存空間
    1x 2.5-inch SATA 6.0 Gb/s HDD/SSD bay
  • 光盤
  • mSATA
  • M.2
    1x M.2 2242/2260 key-M socket for SATA SSD
  • 讀卡器
    SD/SDHC/SDXC card reader
輸入/輸出口
  • 音效
    3.5mm Stereo out & Microphone combo
  • USB接口
    3x USB 3.0
    1x USB 3.0 Type-C
  • 有線網絡
    Dual 10/100/1000 Mbps Ethernet
  • 天線
    SMA WIFI antenna socket
  • Wifi
    IEEE 802.11ac/a/b/g/n WIFI
  • 藍牙
  • Legacy I/O
    RS-232 serial port
  • 紅外線接口
  • Thunderbolt
  • IDE
機械
  • Kensington Lock
  • LED燈
  • 電源
    DC 19V/40W
  • 散熱系統
    Passive cooling
  • ZBOX 尺寸
    160mm x 126.7mm x 58.7mm (6.30in x 4.99in x 2.31in)
  • Case Mounting
其他
  • 支援作業系統
    Microsoft Windows 10, Ubuntu 16.04 LTS
  • 配件
    1x L-shaped Mounting Kit (w/ 4 screws)
    1x VESA mounting kit (w/ 4 screws)
    1x Dual-band antenna
    1x Universal AC adapter
    Power Cord (bundled cable type dependent on region)
    USB flash with software & user's manual
